WP503HDT
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy WP503HDT with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy WP503HDT with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | WP503HDT |
|---|---|
| Manufacturer | Kingbright |
| Description | LED RED DIFF SQUARE TYPE LED T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1000 pcs | ||||
|---|---|---|---|---|---|
| $0.033 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | WP503HDT | Manufacturer | Kingbright |
|---|---|---|---|
| Description | LED RED DIFF SQUARE TYPE LED T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 737381 pcs | Data sheet | WP503HDT |
| Category | Optoelectronics | Wavelength - Peak | 700nm |
| Wavelength - Dominant | 635nm | Voltage - Forward (Vf) (Typ) | 2.25V |
| Viewing Angle | 110° | Supplier Device Package | Square Type LED |
| Size / Dimension | - | Series | - |
| Packaging | Bulk | Package / Case | Radial |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Millicandela Rating | 0.8mcd | Manufacturer Standard Lead Time | 9 Weeks |
| Lens Transparency | Diffused | Lens Style/Size | Square with Flat Top, 5.00mm |
| Lens Color | Red | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height (Max) | 7.20mm | Features | - |
| Detailed Description | Red 635nm LED Indication - Discrete 2.25V Radial | Current - Test | 20mA |
| Configuration | Standard | Color | Red |
