Home > Products > Filters > Common Mode Chokes > SSR21HS-12115

SSR21HS-12115

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SSR21HS-12115 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	SSR21HS-12115
Manufacturer	KEMET
Description	CMC 11.5MH 1.2A 2LN TH
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs	5000 pcs
~~In Stock~~ 121487 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
	$0.563	$0.55	$0.368	$0.328	$0.30
	$0.269	$0.264	$0.191	$0.168

Product parameter
Data sheet

Product parameter

Part Number	SSR21HS-12115	Manufacturer	KEMET
Description	CMC 11.5MH 1.2A 2LN TH	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	121487 pcs	Data sheet	SSR21HS Series
Category	Filters	Voltage Rating - DC	250V
Voltage Rating - AC	-	Size / Dimension	0.906" L x 0.906" W (23.00mm x 23.00mm)
Series	SSR21HS	Ratings	-
Packaging	Bulk	Package / Case	Vertical, 4 PC Pin
Other Names	399-10787	Operating Temperature	-25°C ~ 120°C
Number of Lines	2	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	24 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Inductance @ Frequency	11.5mH @ 10kHz
Height (Max)	0.571" (14.50mm)	Filter Type	Power Line
Features	-	Detailed Description	11.5mH @ 10kHz 2 Line Common Mode Choke Through Hole 1.2A DCR 270 mOhm
DC Resistance (DCR) (Max)	270 mOhm	Current Rating (Max)	1.2A
Approvals	-
