EST477M100AN5AA
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EST477M100AN5AA with confidence from Components-World.HK, 1 Year Warranty
Dowload EST477M100AN5AA Details in PDFSee Product Specifications for product details.
Buy EST477M100AN5AA with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | EST477M100AN5AA |
|---|---|
| Manufacturer | KEMET |
| Description | CAP ALUM 470UF 20% 100V T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | |
|---|---|---|---|---|---|
| $0.813 | $0.659 | $0.503 | $0.383 | ||
| 1000 pcs | 2500 pcs | 5000 pcs | |||
| $0.335 | $0.323 | $0.311 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | EST477M100AN5AA | Manufacturer | KEMET |
|---|---|---|---|
| Description | CAP ALUM 470UF 20% 100V T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 75789 pcs | Data sheet | EST Series |
| Category | Capacitors | Voltage - Rated | 100V |
| Tolerance | ±20% | Surface Mount Land Size | - |
| Size / Dimension | 0.709" Dia (18.00mm) | Series | EST |
| Ripple Current @ Low Frequency | 420mA @ 120Hz | Ripple Current @ High Frequency | 840mA @ 100kHz |
| Ratings | - | Polarization | Polar |
| Packaging | Bulk | Package / Case | Radial, Can |
| Other Names | 399-15749 ST477M100AN5AAKPLP |
Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 20 Weeks | Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Lead Spacing | 0.295" (7.50mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 1.063" (27.00mm) | ESR (Equivalent Series Resistance) | 500 mOhm @ 100kHz |
| Detailed Description | 470µF 100V Aluminum Electrolytic Capacitors Radial, Can 500 mOhm @ 100kHz 10000 Hrs @ 105°C | Capacitance | 470µF |
| Applications | General Purpose |
