Home > Products > Relays > Signal Relays, Up to 2 Amps > EC2-9TNU

EC2-9TNU

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EC2-9TNU with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	EC2-9TNU
Manufacturer	KEMET
Description	RELAY GEN PURPOSE DPDT 2A 250V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4951 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	EC2-9TNU	Manufacturer	KEMET
Description	RELAY GEN PURPOSE DPDT 2A 250V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4951 pcs	Data sheet	EC2-9TNU Spec
Category	Relays	Turn On Voltage (Max)	6.75 VDC
Turn Off Voltage (Min)	-	Termination Style	PC Pin
Switching Voltage	250VAC, 220VDC - Max	Series	EC2
Release Time	1ms	Relay Type	General Purpose
Packaging	Tube	Other Names	399-11061-5
Operating Temperature	-40°C ~ 85°C	Operate Time	2ms
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Features	-
Detailed Description	General Purpose Relay DPDT (2 Form C) Through Hole	Contact Rating (Current)	2A
Contact Material	Silver Alloy, Gold Alloy	Contact Form	DPDT (2 Form C)
Coil Voltage	9VDC	Coil Type	Latching, Dual Coil
Coil Resistance	579 Ohms	Coil Power	140 mW
Coil Current	15.6mA
