BM02(3)B-ADHSS-GAN-ETB(LF)(SN)
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy BM02(3)B-ADHSS-GAN-ETB(LF)(SN) with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy BM02(3)B-ADHSS-GAN-ETB(LF)(SN) with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | BM02(3)B-ADHSS-GAN-ETB(LF)(SN) |
|---|---|
| Manufacturer | JST |
| Description | CONN HEADER 3POS (2 LOADED) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 5000 pcs | 10000 pcs | 15000 pcs | 25000 pcs | |
|---|---|---|---|---|---|
| $0.08 | $0.074 | $0.073 | $0.071 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | BM02(3)B-ADHSS-GAN-ETB(LF)(SN) | Manufacturer | JST |
|---|---|---|---|
| Description | CONN HEADER 3POS (2 LOADED) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 335164 pcs | Data sheet | ADH Series Datasheet |
| Category | Connectors, Interconnects | Voltage Rating | 30V |
| Termination | Solder | Style | Board to Cable/Wire |
| Shrouding | Shrouded - 3 Wall | Series | ADH |
| Row Spacing - Mating | - | Pitch - Mating | 0.051" (1.30mm) |
| Packaging | Tape & Reel (TR) | Overall Contact Length | - |
| Other Names | 455-2895-2 BM023BADHSSGANETBLFSN |
Operating Temperature | -25°C ~ 85°C |
| Number of Rows | 1 | Number of Positions Loaded | 2 |
| Number of Positions | 3 | Mounting Type | Surface Mount, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 24 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Thermoplastic |
| Insulation Height | 0.069" (1.75mm) | Insulation Color | White |
| Ingress Protection | - | Features | Solder Retention |
| Fastening Type | Detent Lock | Detailed Description | Connector Header Surface Mount, Right Angle 3 position 0.051" (1.30mm) |
| Current Rating | 3A | Contact Type | Male Blade |
| Contact Shape | Rectangular | Contact Material | Copper Alloy |
| Contact Length - Post | - | Contact Length - Mating | - |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | - |
| Contact Finish - Post | - | Contact Finish - Mating | Gold |
| Connector Type | Header | Applications | - |
