09DB-8M
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09DB-8M with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 09DB-8M with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 09DB-8M |
|---|---|
| Manufacturer | JST |
| Description | CONN IDC DB 9POS 2.5MM GRN PCB |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 500 pcs | ||||
|---|---|---|---|---|---|
| $0.162 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 09DB-8M | Manufacturer | JST |
|---|---|---|---|
| Description | CONN IDC DB 9POS 2.5MM GRN PCB | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 140652 pcs | Data sheet | DB Series |
| Category | Connectors, Interconnects | Wire Gauge | 24-28 AWG, Stranded |
| Series | DB | Row Spacing | - |
| Packaging | Bulk | Other Names | 455-1077 |
| Number of Rows | 1 | Number of Positions Loaded | All |
| Number of Positions | 9 | Mounting Type | Through Hole, Press-Fit |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 24 Weeks |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Features | Closed End |
| Detailed Description | 9 Position Individual Wires Connector Green IDC 24-28 AWG, Stranded Through Hole, Press-Fit | Contact Finish Thickness | - |
| Contact Finish | Tin-Lead | Connector Type | Individual Wires |
| Color | Green | Cable Termination | IDC |
| Cable Pitch | 0.098" (2.50mm) | Board-Side Pitch | 0.098" (2.50mm) |
