NJM2846DL3-03-TE1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NJM2846DL3-03-TE1 with confidence from Components-World.HK, 1 Year Warranty
Dowload NJM2846DL3-03-TE1 Details in PDFSee Product Specifications for product details.
Buy NJM2846DL3-03-TE1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | NJM2846DL3-03-TE1 |
|---|---|
| Manufacturer | JRC Corporation / NJRC |
| Description | IC REG LINEAR 3V 800MA TO252-5 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | ||||
|---|---|---|---|---|---|
| $0.134 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | NJM2846DL3-03-TE1 | Manufacturer | JRC Corporation / NJRC |
|---|---|---|---|
| Description | IC REG LINEAR 3V 800MA TO252-5 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 146969 pcs | Data sheet | NJM2845_NJM2846 |
| Category | Integrated Circuits (ICs) | Voltage Dropout (Max) | 0.28V @ 500mA |
| Voltage - Output (Min/Fixed) | 3V | Voltage - Output (Max) | - |
| Voltage - Input (Max) | 14V | Supplier Device Package | TO-252-5 |
| Series | - | Protection Features | Over Temperature, Short Circuit |
| Packaging | Tape & Reel (TR) | Package / Case | TO-252-6, DPak (5 Leads + Tab) |
| PSRR | 75dB (1kHz) | Output Type | Fixed |
| Output Configuration | Positive | Other Names | NJM#2846DL3-03-TE1 NJM2846DL2-03-TE1 NJM2846DL203TE1TR NJM2846DL203TE1TR-ND NJM2846DL3-03-TE1TR NJM2846DL303TE1#TR NJM2846DL303TE1#TR-ND NJM2846DL303TE1TR NJM2846DL303TE1TR-ND |
| Operating Temperature | -40°C ~ 85°C | Number of Regulators | 1 |
| Mounting Type | Surface Mount | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Detailed Description | Linear Voltage Regulator IC Positive Fixed 1 Output 3V 800mA TO-252-5 |
| Current - Quiescent (Iq) | 600µA | Current - Output | 800mA |
| Control Features | Enable |
