DP1R020JQ3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DP1R020JQ3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DP1R020JQ3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DP1R020JQ3 |
|---|---|
| Manufacturer | JAE Electronics, Inc. |
| Description | CONN RCPT 20POS RT ANG TOP MNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $0.986 | $0.947 | $0.789 | |||
| 500 pcs | 1000 pcs | 5000 pcs | |||
| $0.671 | $0.572 | $0.513 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | DP1R020JQ3 | Manufacturer | JAE Electronics, Inc. |
|---|---|---|---|
| Description | CONN RCPT 20POS RT ANG TOP MNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 69971 pcs | Data sheet | DP1R020JQ3 DrawingDP1 Series DatasheetInput-Output Selection Guide |
| Category | Connectors, Interconnects | Voltage - Rated | - |
| Termination | Solder | Specifications | Display Port 1.1a |
| Shielding | Unshielded | Shell/Shielding Material | Copper Alloy |
| Series | DP1 | Packaging | Tray |
| Other Names | 670-2430 | Operating Temperature | -20°C ~ 85°C |
| Number of Ports | 1 | Number of Contacts | 20 |
| Mounting Type | Surface Mount, Right Angle; Through Hole | Mounting Feature | Flange, Horizontal |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 10000 |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 14 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Color | Black |
| Ingress Protection | - | Gender | Receptacle |
| Features | - | Detailed Description | DisplayPort Display Port 1.1a Receptacle Connector 20 Position Surface Mount, Right Angle; Through Hole |
| Current Rating | 0.5A per Contact | Contact Finish | Gold |
| Connector Type | DisplayPort |
