Home > Products > Integrated Circuits (ICs) > PMIC - Voltage Regulators - Linear > ISL80138IVEAJZ

ISL80138IVEAJZ

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ISL80138IVEAJZ with confidence from Components-World.HK, 1 Year Warranty

Dowload ISL80138IVEAJZ Details in PDF

Request a Quote

Part Number	ISL80138IVEAJZ
Manufacturer	Intersil
Description	IC REG LIN POS ADJ 14HTSSOP
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 59297 pcs
Reference Price (In US Dollars)	1920 pcs
Reference Price (In US Dollars)	$0.327

Product parameter
Data sheet

Product parameter

Part Number	ISL80138IVEAJZ	Manufacturer	Intersil
Description	IC REG LIN POS ADJ 14HTSSOP	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	59297 pcs	Data sheet	ISL80138
Category	Integrated Circuits (ICs)	Voltage Dropout (Max)	0.507V @ 150mA
Voltage - Output (Min/Fixed)	2.5V	Voltage - Output (Max)	12V
Voltage - Input (Max)	40V	Supplier Device Package	14-HTSSOP
Series	-	Protection Features	Over Current, Over Temperature, Soft Start
Packaging	Tube	Package / Case	14-TSSOP (0.173", 4.40mm Width) Exposed Pad
PSRR	66dB (100Hz)	Output Type	Adjustable
Output Configuration	Positive	Operating Temperature	-40°C ~ 125°C
Number of Regulators	1	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	2 (1 Year)	Manufacturer Standard Lead Time	15 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Detailed Description	Linear Voltage Regulator IC Positive Adjustable 1 Output 2.5 V ~ 12 V 150mA 14-HTSSOP
Current - Supply (Max)	125µA	Current - Quiescent (Iq)	24µA
Current - Output	150mA	Control Features	Enable
Base Part Number	ISL80138
