Home > Products > Integrated Circuits (ICs) > Interface - Drivers, Receivers, Transceivers > BBT3420-SN

BBT3420-SN

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy BBT3420-SN with confidence from Components-World.HK, 1 Year Warranty

Dowload BBT3420-SN Details in PDF

Request a Quote

Part Number	BBT3420-SN
Manufacturer	Intersil
Description	IC TXRX 12.75GBPS 289BGA
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 5553 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	BBT3420-SN	Manufacturer	Intersil
Description	IC TXRX 12.75GBPS 289BGA	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	5553 pcs	Data sheet	BBT3420
Category	Integrated Circuits (ICs)	Voltage - Supply	1.7 V ~ 1.9 V
Type	Transceiver	Supplier Device Package	289-BGA (19x19)
Series	-	Protocol	XAUI, XGMII, MDC/MDIO
Packaging	Tray	Package / Case	289-BGA
Operating Temperature	0°C ~ 70°C	Number of Drivers/Receivers	4/4
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	3 (168 Hours)
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant	Duplex	Full
Detailed Description	4/4 Transceiver Full XAUI, XGMII, MDC/MDIO 289-BGA (19x19)	Data Rate	12.75Gbps
Base Part Number	BBT3420
