IRF6810STR1PBF
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy IRF6810STR1PBF with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy IRF6810STR1PBF with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | IRF6810STR1PBF |
|---|---|
| Manufacturer | International Rectifier (Infineon Technologies) |
| Description | MOSFET N CH 25V 16A S1 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | IRF6810STR1PBF | Manufacturer | International Rectifier (Infineon Technologies) |
|---|---|---|---|
| Description | MOSFET N CH 25V 16A S1 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5772 pcs | Data sheet | IRF6810STR (1) PBF |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 2.1V @ 25µA |
| Vgs (Max) | ±16V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | DIRECTFET S1 | Series | HEXFET® |
| Rds On (Max) @ Id, Vgs | 5.2 mOhm @ 16A, 10V | Power Dissipation (Max) | 2.1W (Ta), 20W (Tc) |
| Packaging | Cut Tape (CT) | Package / Case | DirectFET™ Isometric S1 |
| Other Names | IRF6810STR1PBFCT | Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 1038pF @ 13V |
| Gate Charge (Qg) (Max) @ Vgs | 11nC @ 4.5V | FET Type | N-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Drain to Source Voltage (Vdss) | 25V | Detailed Description | N-Channel 25V 16A (Ta), 50A (Tc) 2.1W (Ta), 20W (Tc) Surface Mount DIRECTFET S1 |
| Current - Continuous Drain (Id) @ 25°C | 16A (Ta), 50A (Tc) |
