Home > Products > Integrated Circuits (ICs) > PMIC - Voltage Regulators - DC DC Switching Regula > IP1001

IP1001

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy IP1001 with confidence from Components-World.HK, 1 Year Warranty

Dowload IP1001 Details in PDF

Request a Quote

Part Number	IP1001
Manufacturer	International Rectifier (Infineon Technologies)
Description	IC REG BUCK ADJ 20A SYNC 256BGA
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 4962 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	IP1001	Manufacturer	International Rectifier (Infineon Technologies)
Description	IC REG BUCK ADJ 20A SYNC 256BGA	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	4962 pcs	Data sheet	IP1001
Category	Integrated Circuits (ICs)	Voltage - Output (Min/Fixed)	0.925V
Voltage - Output (Max)	2V	Voltage - Input (Min)	3.3V
Voltage - Input (Max)	12V	Topology	Buck
Synchronous Rectifier	Yes	Supplier Device Package	218-BGA Power Block (14x14)
Series	iPOWIR™	Packaging	Bulk
Package / Case	218-BFBGA Power Module	Output Type	Adjustable
Output Configuration	Positive	Other Names	*IP1001
Operating Temperature	-40°C ~ 125°C (TJ)	Number of Outputs	1
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	3 (168 Hours)
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant	Function	Step-Down
Frequency - Switching	200kHz, 300kHz	Detailed Description	Buck Switching Regulator IC Positive Adjustable 0.925V 1 Output 20A 218-BFBGA Power Module
Current - Output	20A	Base Part Number	IP1001
