IKW15N120T2FKSA1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy IKW15N120T2FKSA1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy IKW15N120T2FKSA1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | IKW15N120T2FKSA1 |
|---|---|
| Manufacturer | International Rectifier (Infineon Technologies) |
| Description | IGBT 1200V 30A 235W TO247-3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 240 pcs | ||||
|---|---|---|---|---|---|
| $1.455 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | IKW15N120T2FKSA1 | Manufacturer | International Rectifier (Infineon Technologies) |
|---|---|---|---|
| Description | IGBT 1200V 30A 235W TO247-3 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 21528 pcs | Data sheet | IKW15N120T2 |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 1200V |
| Vce(on) (Max) @ Vge, Ic | 2.2V @ 15V, 15A | Test Condition | 600V, 15A, 41.8 Ohm, 15V |
| Td (on/off) @ 25°C | 32ns/362ns | Switching Energy | 2.05mJ |
| Supplier Device Package | PG-TO247-3 | Series | TrenchStop® |
| Reverse Recovery Time (trr) | 300ns | Power - Max | 235W |
| Packaging | Tube | Package / Case | TO-247-3 |
| Other Names | IKW15N120T2 IKW15N120T2-ND SP000244961 |
Operating Temperature | -40°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 52 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Type | Standard | IGBT Type | Trench |
| Gate Charge | 93nC | Detailed Description | IGBT Trench 1200V 30A 235W Through Hole PG-TO247-3 |
| Current - Collector Pulsed (Icm) | 60A | Current - Collector (Ic) (Max) | 30A |
