ICE3AR0680JZXKLA1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ICE3AR0680JZXKLA1 with confidence from Components-World.HK, 1 Year Warranty
Dowload ICE3AR0680JZXKLA1 Details in PDFSee Product Specifications for product details.
Buy ICE3AR0680JZXKLA1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ICE3AR0680JZXKLA1 |
|---|---|
| Manufacturer | International Rectifier (Infineon Technologies) |
| Description | IC OFFLINE CTRLR SMPS CM 7DIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $1.125 | $1.01 | $0.812 | $0.667 | $0.553 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | ICE3AR0680JZXKLA1 | Manufacturer | International Rectifier (Infineon Technologies) |
|---|---|---|---|
| Description | IC OFFLINE CTRLR SMPS CM 7DIP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 58614 pcs | Data sheet | ICE3AR0680JZ |
| Category | Integrated Circuits (ICs) | Voltage - Supply (Vcc/Vdd) | 10.5 V ~ 27 V |
| Voltage - Start Up | 17V | Voltage - Breakdown | 800V |
| Topology | Flyback | Supplier Device Package | PG-DIP-7 |
| Series | CoolMOS™, CoolSET™F3R | Power (Watts) | 82W |
| Packaging | Tube | Package / Case | 8-DIP (0.300", 7.62mm), 7 Leads |
| Output Isolation | Isolated | Other Names | SP000848680 |
| Operating Temperature | -40°C ~ 150°C (TJ) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 20 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Internal Switch(s) | Yes |
| Frequency - Switching | 100kHz | Fault Protection | Over Load, Over Temperature, Over Voltage |
| Duty Cycle | 75% | Detailed Description | Converter Offline Flyback Topology 100kHz PG-DIP-7 |
| Control Features | - |
