Home > Products > Discrete Semiconductor Products > Diodes - Rectifiers - Arrays > DD180N16SHPSA1

DD180N16SHPSA1

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DD180N16SHPSA1 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	DD180N16SHPSA1
Manufacturer	International Rectifier (Infineon Technologies)
Description	DIODE MODULE GP 1600V 192A
Lead Free Status / RoHS Status

~~In Stock~~ 2477 pcs
Reference Price (In US Dollars)	1 pcs	16 pcs
Reference Price (In US Dollars)	$16.82	$15.692

Product parameter
Data sheet

Product parameter

Part Number	DD180N16SHPSA1	Manufacturer	International Rectifier (Infineon Technologies)
Description	DIODE MODULE GP 1600V 192A	Lead Free Status / RoHS Status
Quantity Available	2477 pcs	Data sheet	DD180N
Category	Discrete Semiconductor Products	Voltage - Forward (Vf) (Max) @ If	1.39V @ 500A
Voltage - DC Reverse (Vr) (Max)	1600V	Supplier Device Package	Module
Speed	Standard Recovery >500ns, > 200mA (Io)	Series	-
Packaging	Bulk	Package / Case	Module
Other Names	DD180N16S DD180N16S-ND SP001495438	Operating Temperature - Junction	-40°C ~ 125°C
Mounting Type	Chassis Mount	Manufacturer Standard Lead Time	12 Weeks
Diode Type	Standard	Diode Configuration	1 Pair Series Connection
Detailed Description	Diode Array 1 Pair Series Connection Standard 1600V 192A Chassis Mount Module	Current - Reverse Leakage @ Vr	1mA @ 1600V
Current - Average Rectified (Io) (per Diode)	192A
