Home > Products > Discrete Semiconductor Products > Diodes - Rectifiers - Single > DSA75-16B

DSA75-16B

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DSA75-16B with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	DSA75-16B
Manufacturer	IXYS Corporation
Description	DIODE AVALANCHE 1.6KV 110A DO203
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 2816 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	100 pcs
Reference Price (In US Dollars)	$14.623	$13.675	$11.857

Product parameter
Data sheet

Product parameter

Part Number	DSA75-16B	Manufacturer	IXYS Corporation
Description	DIODE AVALANCHE 1.6KV 110A DO203	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	2816 pcs	Data sheet	DS(A,I,AI)75
Category	Discrete Semiconductor Products	Voltage - Forward (Vf) (Max) @ If	1.17V @ 150A
Voltage - DC Reverse (Vr) (Max)	1600V	Supplier Device Package	DO-203AB
Speed	Standard Recovery >500ns, > 200mA (Io)	Series	-
Packaging	Bulk	Package / Case	DO-203AB, DO-5, Stud
Other Names	DSA7516B Q3238069	Operating Temperature - Junction	-40°C ~ 180°C
Mounting Type	Chassis, Stud Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	32 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Diode Type	Avalanche	Detailed Description	Diode Avalanche 1600V 110A Chassis, Stud Mount DO-203AB
Current - Reverse Leakage @ Vr	6mA @ 1600V	Current - Average Rectified (Io)	110A
Capacitance @ Vr, F	-
