DHH55-36N1F
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DHH55-36N1F with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DHH55-36N1F with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DHH55-36N1F |
|---|---|
| Manufacturer | IXYS Corporation |
| Description | DIODE ARRAY GP 1800V 60A I4PAC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 25 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $7.829 | $6.585 | $6.051 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | DHH55-36N1F | Manufacturer | IXYS Corporation |
|---|---|---|---|
| Description | DIODE ARRAY GP 1800V 60A I4PAC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5851 pcs | Data sheet | DHH55-36N1F |
| Category | Discrete Semiconductor Products | Voltage - Forward (Vf) (Max) @ If | 2.04V @ 60A |
| Voltage - DC Reverse (Vr) (Max) | 1800V | Supplier Device Package | i4-PAC™ |
| Speed | Fast Recovery = 200mA (Io) | Series | - |
| Reverse Recovery Time (trr) | 230ns | Packaging | Tube |
| Package / Case | i4-Pac™-3 | Other Names | DHH 55-36N1F DHH5536N1F |
| Operating Temperature - Junction | -55°C ~ 150°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 32 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Diode Type | Standard |
| Diode Configuration | 1 Pair Series Connection | Detailed Description | Diode Array 1 Pair Series Connection Standard 1800V 60A Through Hole i4-Pac™-3 |
| Current - Reverse Leakage @ Vr | 200µA @ 1800V | Current - Average Rectified (Io) (per Diode) | 60A |
