Home > Products > Switches > Snap Action, Limit Switches > ZX40E30C01

ZX40E30C01

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ZX40E30C01 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	ZX40E30C01
Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION SPDT 3A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs	5000 pcs
~~In Stock~~ 74068 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
	$1.194	$0.817	$0.735	$0.688	$0.65
	$0.609	$0.583	$0.56	$0.515

Product parameter
Data sheet

Product parameter

Part Number	ZX40E30C01	Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION SPDT 3A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	74068 pcs	Data sheet	Basic, Toggle, Rocker Switches Range Guide Basic Switches Line Guide ZX Series Datasheet Z Series Install Instr
Category	Switches	Voltage Rating - AC	125V
Termination Style	PC Pin	Switch Function	On-Mom
Series	ZX	Release Force	8.000gf
Pretravel	0.134" (3.4mm)	Packaging	Bulk
Overtravel	0.025" (0.6mm)	Other Names	480-5342 ZX40E30C01-ND
Operating Temperature	-40°C ~ 120°C	Operating Position	0.330" (8.4mm)
Operating Force	48gf	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	1,000,000 Cycles
Manufacturer Standard Lead Time	8 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Features	-
Electrical Life	10,000 Cycles	Differential Travel	0.050" (1.3mm)
Current Rating	3A (AC)	Circuit	SPDT
Actuator Type	Lever, Straight
