Home > Products > Switches > Snap Action, Limit Switches > YZ-2RDS4

YZ-2RDS4

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy YZ-2RDS4 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	YZ-2RDS4
Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACT SPST-NO 15A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 2872 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$10.413

Product parameter
Data sheet

Product parameter

Part Number	YZ-2RDS4	Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACT SPST-NO 15A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	2872 pcs	Data sheet	YZ-2RDS4 Drawing BZ,BA,BM,6AS,W,Y Series
Category	Switches	Voltage Rating - DC	125V
Voltage Rating - AC	125V	Termination Style	Screw Terminal
Switch Function	Off-Mom	Series	YZ
Release Force	113gf	Pretravel	-
Packaging	Bulk	Overtravel	0.060" (1.5mm)
Other Names	480-5330 YZ-2RDS4-ND YZ2RDS4	Operating Temperature	-55°C ~ 85°C
Operating Position	1.110" (28.2mm)	Operating Force	368 ~ 538gf
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	20,000,000 Cycles	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	Splash Proof	Features	-
Electrical Life	-	Differential Travel	0.002" (0.05mm)
Current Rating	15A (AC), 500mA (DC)	Circuit	SPST-NO
Actuator Type	Round (Pin Plunger)
