Home > Products > Switches > Snap Action, Limit Switches > SCN-2209SC

SCN-2209SC

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SCN-2209SC with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	SCN-2209SC
Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION SPDT 10A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 5287 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	SCN-2209SC	Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION SPDT 10A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	5287 pcs	Data sheet	BZ,BA,BM,6AS,W,Y Series
Category	Switches	Voltage Rating - DC	125V
Voltage Rating - AC	125V	Termination Style	Screw Terminal
Switch Function	On-Mom	Series	BZ
Release Force	43gf	Pretravel	-
Packaging	Bulk	Overtravel	0.094" (2.4mm)
Other Names	480-4700 BZ-3RW8221555513T-S BZ-3RW8221555513T-S-ND SCN2209SC	Operating Temperature	-55°C ~ 85°C
Operating Position	1.188" (30.2mm)	Operating Force	184gf
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	20,000,000 Cycles	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	Splash Proof	Features	-
Electrical Life	-	Differential Travel	0.030" (0.76mm)
Current Rating	10A (AC), 500mA (DC)	Circuit	SPDT
Actuator Type	Lever, Roller
