Home > Products > Switches > Snap Action, Limit Switches > LSXM4N

LSXM4N

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LSXM4N with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	LSXM4N
Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION DPDT 10A 120V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 5618 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	LSXM4N	Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION DPDT 10A 120V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	5618 pcs	Data sheet	LSX Series Catalog LSX Series Install Instr Machine Safety Range Guide Hazardous Area Switches Line Guide LSX Series Datasheet
Category	Switches	Voltage Rating - DC	115V
Voltage Rating - AC	120V	Termination Style	Screw Terminal
Switch Function	Mom-Off-Mom	Series	LSX
Release Force	-	Pretravel	18°
Packaging	Bulk	Overtravel	57°
Other Names	480-5066 LSXM4N-ND	Operating Temperature	-1°C ~ 121°C
Operating Position	-	Operating Force	46gfm
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Features	Explosion Proof
Electrical Life	-	Differential Travel	10°
Current Rating	10A (AC), 800mA (DC)	Circuit	DPDT (DB/DM)
Actuator Type	Side Rotary - No Lever
