Home > Products > Switches > Snap Action, Limit Switches > LSM4N

LSM4N

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LSM4N with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	LSM4N
Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION DPDT 10A 120V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 560 pcs
Reference Price (In US Dollars)	3 pcs
Reference Price (In US Dollars)	$68.634

Product parameter
Data sheet

Product parameter

Part Number	LSM4N	Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION DPDT 10A 120V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	560 pcs	Data sheet	HDLS Series Datasheet
Category	Switches	Voltage Rating - DC	115V
Voltage Rating - AC	120V	Termination Style	Screw Terminal
Switch Function	Mom-Off-Mom	Series	HDLS
Release Force	-	Pretravel	18°
Packaging	Bulk	Overtravel	57°
Other Names	480-5038 LSM4N-ND	Operating Temperature	-1°C ~ 121°C
Operating Position	-	Operating Force	46gfm
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	-	Manufacturer Standard Lead Time	4 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Features	Center Neutral	Electrical Life	-
Differential Travel	10°	Current Rating	10A (AC), 800mA (DC)
Circuit	DPDT (DB/DM)	Actuator Type	Side Rotary - No Lever
