MDF7-26DP-2.54DSA(55)
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MDF7-26DP-2.54DSA(55) with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MDF7-26DP-2.54DSA(55) with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MDF7-26DP-2.54DSA(55) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | CONN HDR 26POS 2.54MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 100 pcs | ||||
|---|---|---|---|---|---|
| $0.664 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | MDF7-26DP-2.54DSA(55) | Manufacturer | Hirose Electric Co Ltd |
|---|---|---|---|
| Description | CONN HDR 26POS 2.54MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 49289 pcs | Data sheet | MDF7 Series |
| Category | Connectors, Interconnects | Termination | Solder |
| Stacking Direction | Male Pin | Shrouding | 0.100" (2.54mm) |
| Series | MDF7 | Row Spacing - Mating | Unshrouded |
| RoHS Status | Bulk | Other Names | 547-0251-5-55 |
| Number of Rows | 2 | Number of Positions | 26 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Insulation | All | Manufacturer Standard Lead Time | 8 Weeks |
| Manufacturer Part Number | MDF7-26DP-2.54DSA(55) | Features | - |
| Expanded Description | 26 Positions Header Connector 0.100" (2.54mm) Through Hole Tin | Description | CONN HDR 26POS 2.54MM |
| Current - Max/Contact | - | Contact Length - Post | 0.394" (10.00mm) |
| Contact Length - Mating | 0.100" (2.54mm) | Contact Finish Thickness - Mating | Tin |
| Contact Finish - Post | 39µin (1.00µm) | Connector Type | Header |
| Actual Diameter | Black |
