Home > Products > RF/IF and RFID > RF Directional Coupler > HDH-00820GID(40)

HDH-00820GID(40)

HDH-00820GID(40)

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HDH-00820GID(40) with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	HDH-00820GID(40)
Manufacturer	Hirose
Description	RF DIR COUPLER 750MHZ
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 313 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$111.325

Product parameter
Data sheet

Product parameter

Part Number	HDH-00820GID(40)	Manufacturer	Hirose
Description	RF DIR COUPLER 750MHZ	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	313 pcs	Data sheet	HDH Series HDH Series Flyer
Category	RF/IF and RFID	Supplier Device Package	-
Series	HDH	Return Loss	23dB
Power - Max	50W	Packaging	Bulk
Package / Case	-	Other Names	H11876 HDH00820GID40
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Isolation	38dB	Insertion Loss	0.3dB
Frequency	750MHz	Detailed Description	RF Directional Coupler General Purpose 750MHz 20dB 50W
Coupling Factor	20dB	Coupler Type	Standard
Applications	General Purpose
