GX60-18P(30)
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy GX60-18P(30) with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy GX60-18P(30) with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | GX60-18P(30) |
|---|---|
| Manufacturer | Hirose |
| Description | CONN RCPT 18POS R/A W/PIN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1500 pcs | ||||
|---|---|---|---|---|---|
| $0.248 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | GX60-18P(30) | Manufacturer | Hirose |
|---|---|---|---|
| Description | CONN RCPT 18POS R/A W/PIN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 79642 pcs | Data sheet | GX Series Catalog |
| Category | Connectors, Interconnects | Voltage Rating | 30V |
| Termination | Solder | Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall | Series | GX |
| Row Spacing - Mating | - | Pitch - Mating | 0.016" (0.40mm) |
| Packaging | Tape & Reel (TR) | Overall Contact Length | - |
| Other Names | 247-0001-3-30 | Operating Temperature | -30°C ~ 80°C |
| Number of Rows | 1 | Number of Positions Loaded | All |
| Number of Positions | 18 | Mounting Type | Surface Mount, Right Angle |
| Material Flammability Rating | UL94 V-0 | Mated Stacking Heights | - |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Liquid Crystal Polymer (LCP) | Insulation Height | 0.138" (3.50mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | Board Lock, Shielded | Fastening Type | Push-Pull |
| Detailed Description | Connector Header Surface Mount, Right Angle 18 position 0.016" (0.40mm) | Current Rating | - |
| Contact Type | Male Pin | Contact Shape | - |
| Contact Material | Copper Alloy | Contact Length - Post | - |
| Contact Length - Mating | - | Contact Finish Thickness - Post | - |
| Contact Finish Thickness - Mating | - | Contact Finish - Post | - |
| Contact Finish - Mating | Gold | Connector Type | Receptacle |
| Applications | - |
