FH52-10(4)SA-1SH
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FH52-10(4)SA-1SH with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy FH52-10(4)SA-1SH with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | FH52-10(4)SA-1SH |
|---|---|
| Manufacturer | Hirose |
| Description | CONN FFC 10POS 1MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | ||||
|---|---|---|---|---|---|
| $0.269 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | FH52-10(4)SA-1SH | Manufacturer | Hirose |
|---|---|---|---|
| Description | CONN FFC 10POS 1MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 71306 pcs | Data sheet | FH52-10(4)SA-1SH DrawingFH52-10(4)SA-1SH SpecFH52 Series Datasheet |
| Category | Connectors, Interconnects | Voltage Rating | 50V |
| Termination | Solder | Series | FH52 |
| Pitch | 0.039" (1.00mm) | Packaging | Tape & Reel (TR) |
| Other Names | 580-3330-0-00 FH52-10(4)SA-1SH-ND H124730TR |
Operating Temperature | -40°C ~ 105°C |
| Number of Positions | 10 (4 Loaded) | Mounting Type | Surface Mount, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 20 |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 12 Weeks |
| Locking Feature | Flip Lock | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Material | Liquid Crystal Polymer (LCP) | Housing Color | Gray |
| Height Above Board | 0.079" (2.00mm) | Flat Flex Type | FFC, FPC |
| Features | - | FFC, FCB Thickness | 0.30mm |
| Detailed Description | 10 (4 Loaded) Position FFC, FPC Connector Contacts, Bottom 0.039" (1.00mm) Surface Mount, Right Angle | Current Rating | 0.5A |
| Contact Material | Phosphor Bronze | Contact Finish Thickness | 1.18µin (0.030µm) |
| Contact Finish | Gold | Connector/Contact Type | Contacts, Bottom |
| Cable End Type | Tabbed | Actuator Material | Liquid Crystal Polymer (LCP) |
| Actuator Color | Black |
