DF50-30DP-1V(52)
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DF50-30DP-1V(52) with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DF50-30DP-1V(52) with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DF50-30DP-1V(52) |
|---|---|
| Manufacturer | Hirose |
| Description | CONN HEADER 30POS 1MM SMD AU |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1000 pcs | ||||
|---|---|---|---|---|---|
| $0.286 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | DF50-30DP-1V(52) | Manufacturer | Hirose |
|---|---|---|---|
| Description | CONN HEADER 30POS 1MM SMD AU | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 80359 pcs | Data sheet | DF50-30DP-1V(52) SpecDF50 SeriesDF50-30DP-1V(52) Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 100V |
| Termination | Solder | Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall | Series | DF50 |
| Row Spacing - Mating | - | Pitch - Mating | 0.039" (1.00mm) |
| Packaging | Tape & Reel (TR) | Overall Contact Length | - |
| Other Names | DF50-30DP-1V(52)-ND H126067TR |
Operating Temperature | -35°C ~ 85°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 30 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | 7.35mm | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Polyester | Insulation Height | 0.278" (7.06mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | Solder Retention | Fastening Type | Latch Lock |
| Detailed Description | Connector Header Surface Mount 30 position 0.039" (1.00mm) | Current Rating | 1A |
| Contact Type | Outer Shroud Contact | Contact Shape | - |
| Contact Material | Brass | Contact Length - Post | - |
| Contact Length - Mating | - | Contact Finish Thickness - Post | - |
| Contact Finish Thickness - Mating | - | Contact Finish - Post | - |
| Contact Finish - Mating | Gold | Connector Type | Header |
| Applications | - |
