DF1E-3P-2.5DS(05)

DF1E-3P-2.5DS(05)
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DF1E-3P-2.5DS(05) with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number DF1E-3P-2.5DS(05)
Manufacturer Hirose
Description CONN HEADER 3POS 2.5MM R/A TIN
Lead Free Status / RoHS Status Lead free / RoHS Compliant
In Stock 5308 pcs
Reference Price
(In US Dollars)		Get a quote

Submit a Request For Quotation on quantities greater than those displayed.

Target Price:(USD)
Quantity:
Total:
$0.00

Product parameter

Part Number DF1E-3P-2.5DS(05) Manufacturer Hirose
Description CONN HEADER 3POS 2.5MM R/A TIN Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 5308 pcs Data sheet DF1E-xP-2.5DS(05) SpecDF1E SeriesDF1E-xP-2.5DS(05) Drawing
Category Connectors, Interconnects Voltage Rating -
Termination Solder Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall Series DF1E
Row Spacing - Mating - Pitch - Mating 0.098" (2.50mm)
Packaging Bulk Overall Contact Length -
Other Names *DF1E-3P-2.5DS(05)
DF1E3P25DS05
H11060		 Operating Temperature -35°C ~ 85°C
Number of Rows 1 Number of Positions Loaded All
Number of Positions 3 Mounting Type Through Hole, Right Angle
Moisture Sensitivity Level (MSL) 1 (Unlimited) Material Flammability Rating UL94 V-0
Mated Stacking Heights - Lead Free Status / RoHS Status Lead free / RoHS Compliant
Insulation Material Polyamide (PA), Nylon Insulation Height 0.315" (8.00mm)
Insulation Color Natural Ingress Protection -
Features - Fastening Type Latch Holder
Detailed Description Connector Header Through Hole, Right Angle 3 position 0.098" (2.50mm) Current Rating 3A
Contact Type Male Pin Contact Shape Square
Contact Material Brass Contact Length - Post 0.114" (2.90mm)
Contact Length - Mating 0.177" (4.50mm) Contact Finish Thickness - Post -
Contact Finish Thickness - Mating 39.4µin (1.00µm) Contact Finish - Post Tin
Contact Finish - Mating Tin Connector Type Header
Applications -
