DF13-40DS-1.25DSA(50)
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DF13-40DS-1.25DSA(50) with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DF13-40DS-1.25DSA(50) with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DF13-40DS-1.25DSA(50) |
|---|---|
| Manufacturer | Hirose |
| Description | CONN RECEPT 40POS 1.25MM GOLD |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | DF13-40DS-1.25DSA(50) | Manufacturer | Hirose |
|---|---|---|---|
| Description | CONN RECEPT 40POS 1.25MM GOLD | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 5903 pcs | Data sheet | DF13-40DS-1.25DSA 01, 50DF13 Series Datasheet |
| Category | Connectors, Interconnects | Voltage Rating | 150VAC |
| Termination | Solder | Style | Board to Board or Cable |
| Series | DF13 | Row Spacing - Mating | 0.049" (1.25mm) |
| Pitch - Mating | 0.049" (1.25mm) | Packaging | Tube |
| Other Names | *DF13-40DS-1.25DSA(5 *DF13-40DS-1.25DSA(50) DF1340DS125DSA50 H3364 |
Operating Temperature | -35°C ~ 85°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 40 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | 6.8mm | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Insulation Material | Polyamide (PA), Nylon | Insulation Height | 0.197" (5.00mm) |
| Insulation Color | Beige | Ingress Protection | - |
| Features | Pick and Place | Fastening Type | Friction Lock |
| Detailed Description | 40 Position Receptacle Connector 0.049" (1.25mm) Through Hole Gold | Current Rating | 1A |
| Contact Type | Female Socket | Contact Shape | Square |
| Contact Material | Phosphor Bronze | Contact Length - Post | 0.079" (2.00mm) |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | - |
| Contact Finish - Post | Tin | Contact Finish - Mating | Gold |
| Connector Type | Receptacle | Applications | General Purpose, Telecommunications |
