M40-3021046
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy M40-3021046 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy M40-3021046 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | M40-3021046 |
|---|---|
| Manufacturer | Harwin |
| Description | 10+10 WAY 1.00MM DIL VERT MALE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | |
|---|---|---|---|---|---|
| $0.65 | $0.59 | $0.505 | $0.421 | ||
| 1000 pcs | 5000 pcs | 10000 pcs | |||
| $0.361 | $0.32 | $0.313 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | M40-3021046 | Manufacturer | Harwin |
|---|---|---|---|
| Description | 10+10 WAY 1.00MM DIL VERT MALE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 76653 pcs | Data sheet | M40-302xx46R Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 50V |
| Termination | Solder | Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall | Series | M40 |
| Row Spacing - Mating | 0.051" (1.30mm) | Pitch - Mating | 0.039" (1.00mm) |
| Packaging | Bulk | Overall Contact Length | - |
| Other Names | 952-3491 | Operating Temperature | -25°C ~ 85°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 20 | Mounting Type | Surface Mount |
| Material Flammability Rating | UL94 V-0 | Mated Stacking Heights | - |
| Manufacturer Standard Lead Time | 7 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Polyamide (PA9T), Nylon 9T | Insulation Height | 0.167" (4.25mm) |
| Insulation Color | - | Ingress Protection | - |
| Features | Board Guide, Pick and Place, Solder Retention | Fastening Type | Detent Lock |
| Detailed Description | Connector Header Surface Mount 20 position 0.039" (1.00mm) | Current Rating | 1A |
| Contact Type | Male Pin | Contact Shape | Rectangular |
| Contact Material | Phosphor Bronze | Contact Length - Post | - |
| Contact Length - Mating | - | Contact Finish Thickness - Post | - |
| Contact Finish Thickness - Mating | - | Contact Finish - Post | Tin |
| Contact Finish - Mating | Tin | Connector Type | Header |
| Applications | - |
