M20-9600545
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy M20-9600545 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy M20-9600545 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | M20-9600545 |
|---|---|
| Manufacturer | Harwin |
| Description | 2X5POS DIL EXTENDED PIN HEADER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | M20-9600545 | Manufacturer | Harwin |
|---|---|---|---|
| Description | 2X5POS DIL EXTENDED PIN HEADER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5680 pcs | Data sheet | M20-960 Drawing |
| Category | Connectors, Interconnects | Termination | Solder |
| Series | M20 | Row Spacing | 0.100" (2.54mm) |
| Pitch | 0.100" (2.54mm) | Packaging | Bulk |
| Other Names | 952-1925 M209600545 |
Number of Rows | 2 |
| Number of Positions | 10 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Length - Tail | 0.118" (3.000mm) |
| Length - Stack Height | 0.661" (16.800mm) | Length - Post (Mating) | 0.283" (7.200mm) |
| Length - Overall Pin | 1.063" (27.000mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Detailed Description | 10 Position Header Spacer Connector 0.100" (2.54mm) Gold Through Hole | Contact Finish Thickness - Post (Mating) | - |
| Contact Finish - Post (Mating) | Gold | Color | Black |
