560N
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 560N with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 560N with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 560N |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSF AUDIO 150/600 10K/40K IMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $19.512 | $18.862 | $17.561 | $16.26 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 560N | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSF AUDIO 150/600 10K/40K IMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2119 pcs | Data sheet | 560 Series |
| Category | Transformers | Weight | 0.25 lb (113.4g) |
| Voltage - Isolation | - | Turns Ratio - Primary:Secondary | - |
| Transformer Type | Broadcast Quality | Termination Style | PC Pin |
| Size / Dimension | 1.330" L x 1.640" W (33.78mm x 41.66mm) | Series | 560 |
| Return Loss | - | Power Level | - |
| Packaging | Bulk | Other Names | 560N-ND HM5158 |
| Operating Temperature | - | Mounting Type | Through Hole |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | 1dB Max | Impedance - Secondary (Ohms) | 40k, 10k/10k |
| Impedance - Primary (Ohms) | 600, 150/150 | Height - Seated (Max) | 0.850" (21.59mm) |
| Frequency Response | ±1dB | Frequency Range | 30Hz ~ 30kHz |
| DC Resistance (DCR) - Secondary | - | DC Resistance (DCR) - Primary | - |
| Approvals | - |
