290AX
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 290AX with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 290AX with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 290AX |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | XFRMR LAMINATED CHAS MOUNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $24.801 | $23.975 | $22.321 | $20.668 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 290AX | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | XFRMR LAMINATED CHAS MOUNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1669 pcs | Data sheet | 1750 Series Catalog Page290AX Drawing |
| Category | Transformers | Weight | 4 lbs (1.8kg) |
| Voltage - Secondary (Full Load) | 650V, 6.3V, 5V | Voltage - Primary | 120V |
| Voltage - Isolation | - | Type | Laminated Core |
| Termination Style | Wire Leads | Size / Dimension | 63.50mm L x 71.55mm W |
| Series | 290 | Secondary Winding(s) | Triple |
| Primary Winding(s) | Single | Power - Max | - |
| Other Names | 290AX-ND HM2148 |
Mounting Type | Chassis Mount |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 77.80mm | Current - Output (Max) | 81mA, 2A, 2A |
| Center Tap | Yes |
