269AX
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 269AX with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 269AX with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 269AX |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | XFRMR LAMINATED 40VA CHAS MOUNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $18.813 | $18.184 | $16.93 | $15.676 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 269AX | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | XFRMR LAMINATED 40VA CHAS MOUNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2057 pcs | Data sheet | 263 - 282 Series Spec.269AX Drawing |
| Category | Transformers | Weight | 1.6 lbs (725.7g) |
| Voltage - Secondary (Full Load) | 250V, 6.3V | Voltage - Primary | 115V |
| Voltage - Isolation | 2000Vrms | Type | Laminated Core |
| Termination Style | Wire Leads | Size / Dimension | 55.63mm L x 63.50mm W |
| Series | 269 | Secondary Winding(s) | Dual |
| Primary Winding(s) | Single | Power - Max | 40 VA |
| Other Names | 269AX-ND HM1571 |
Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | Not Applicable | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 66.80mm |
| Current - Output (Max) | 115mA, 2A | Center Tap | Yes |
