266S24
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 266S24 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 266S24 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 266S24 |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | XFRMR LAMINATED 240VA CHAS MOUNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $39.299 | $37.987 | $35.367 | $32.748 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 266S24 | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | XFRMR LAMINATED 240VA CHAS MOUNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1101 pcs | Data sheet | 266 Series Connection Sheet266x12, 266x16, 266x20, 266x24, 266x48 |
| Category | Transformers | Weight | 8.6 lbs (3.9kg) |
| Voltage - Secondary (Full Load) | Parallel 12V, Series 24V | Voltage - Primary | 117V, 234V |
| Voltage - Isolation | 2000Vrms | Type | Laminated Core |
| Termination Style | Wire Leads | Size / Dimension | 87.38mm L x 91.44mm W |
| Series | 266 | Secondary Winding(s) | Dual |
| Primary Winding(s) | Dual | Power - Max | 240 VA |
| Other Names | 266S24-ND HM2143 |
Mounting Type | Chassis Mount |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 109.22mm | Current - Output (Max) | Parallel 20A, Series 10A |
| Center Tap | No |
