226D
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 226D with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 226D with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 226D |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | XFRMR SEMI-TORO 1VA THRU HOLE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $28.557 | $27.605 | $25.701 | $23.797 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 226D | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | XFRMR SEMI-TORO 1VA THRU HOLE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1627 pcs | Data sheet | 226, 227, 228 Series |
| Category | Transformers | Weight | 0.22 lb (99.79g) |
| Voltage - Secondary (Full Load) | Parallel 10V, Series 20V | Voltage - Primary | 115V |
| Voltage - Isolation | - | Type | Semi-Toroidal |
| Termination Style | PC Pin | Size / Dimension | 43.94mm L x 34.29mm W |
| Series | 226 | Secondary Winding(s) | Dual |
| Primary Winding(s) | Single | Power - Max | 1 VA |
| Other Names | 226D-ND HM4826 |
Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 20.32mm |
| Current - Output (Max) | Parallel 100mA, Series 50mA | Center Tap | No |
