1760C
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1760C with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1760C with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1760C |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER TUBE GUITAR AMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $14.734 | $14.241 | $13.259 | $12.277 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1760C | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER TUBE GUITAR AMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2552 pcs | Data sheet | 1750,1760 Series Spec.1760C Drawing |
| Category | Transformers | Weight | 0.625 lb (283.5g) |
| Voltage - Isolation | - | Turns Ratio - Primary:Secondary | 44.61:1 |
| Transformer Type | Single Ended Audiophile, Ultra-Linear - Tube Output | Termination Style | Wire Leads |
| Size / Dimension | 2.813" L x 1.560" W (71.45mm x 39.62mm) | Series | 1760 |
| Return Loss | - | Power Level | 5W |
| Packaging | Bulk | Other Names | 1760C-ND HM4585 |
| Operating Temperature | - | Mounting Type | Chassis Mount |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Impedance - Secondary (Ohms) | 3.2, 8, 16 |
| Impedance - Primary (Ohms) | 7k | Height - Seated (Max) | 1.746" (44.35mm) |
| Frequency Response | ±1dB | Frequency Range | 70Hz ~ 15kHz |
| DC Resistance (DCR) - Secondary | 292 mOhm | DC Resistance (DCR) - Primary | 284.2 Ohm |
| Approvals | - |
