1182L30
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1182L30 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1182L30 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1182L30 |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER TOROIDAL POWER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $19.842 | $19.179 | $17.856 | $16.533 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1182L30 | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER TOROIDAL POWER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1885 pcs | Data sheet | 1182 Series Spec.1182 Series Connection Sheet1182L30 Drawing |
| Category | Transformers | Weight | 3 lbs (1.4kg) |
| Voltage - Secondary (Full Load) | Parallel 30V, Series 60V | Voltage - Primary | 117V |
| Voltage - Isolation | 4000Vrms | Type | Toroidal |
| Termination Style | Wire Leads | Size / Dimension | 101.60mm Dia |
| Series | 1182 | Secondary Winding(s) | Dual |
| Primary Winding(s) | Dual | Power - Max | 120 VA |
| Other Names | 1182L30-ND HM2452 |
Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | Not Applicable | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 41.40mm |
| Current - Output (Max) | Parallel 4A, Series 2A | Center Tap | No |
