104R
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 104R with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 104R with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 104R |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER AUDIO 500CT/8 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $9.074 | $8.006 | $7.739 | $6.938 | $6.671 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 104R | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER AUDIO 500CT/8 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4926 pcs | Data sheet | 104 Series Spec. |
| Category | Transformers | Weight | 0.05 lb (22.68g) |
| Voltage - Isolation | 200V | Turns Ratio - Primary:Secondary | - |
| Transformer Type | Miniature Epoxy Potted | Termination Style | PC Pin |
| Size / Dimension | 0.860" L x 0.710" W (21.84mm x 18.03mm) | Series | 104 |
| Return Loss | - | Power Level | 500mW |
| Packaging | Bulk | Other Names | 104R-ND HM2355 |
| Operating Temperature | - | Mounting Type | Through Hole |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | 1dB | Impedance - Secondary (Ohms) | 8 |
| Impedance - Primary (Ohms) | 500CT | Height - Seated (Max) | 0.750" (19.05mm) |
| Frequency Response | -1dB | Frequency Range | 200Hz |
| DC Resistance (DCR) - Secondary | 900 mOhm | DC Resistance (DCR) - Primary | 27 Ohm |
| Approvals | - |
