102D
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 102D with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 102D with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 102D |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER AUDIO 600/1500 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $6.948 | $6.132 | $5.927 | $5.314 | $5.11 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 102D | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER AUDIO 600/1500 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6725 pcs | Data sheet | 102 Series Spec. |
| Category | Transformers | Weight | 0.02 lb (9.07g) |
| Voltage - Isolation | 100V | Turns Ratio - Primary:Secondary | - |
| Transformer Type | Miniature Epoxy Potted | Termination Style | PC Pin |
| Size / Dimension | 0.570" L x 0.570" W (14.48mm x 14.48mm) | Series | 102 |
| Return Loss | - | Power Level | 20mW |
| Packaging | Bulk | Other Names | 102D-ND HM2350 |
| Operating Temperature | - | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | Not Applicable | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | 1.5dB |
| Impedance - Secondary (Ohms) | 1.5k | Impedance - Primary (Ohms) | 600 |
| Height - Seated (Max) | 0.480" (12.19mm) | Frequency Response | -1dB |
| Frequency Range | 310Hz | DC Resistance (DCR) - Secondary | 85 Ohm |
| DC Resistance (DCR) - Primary | 43 Ohm | Approvals | - |
