TSDB320P
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TSDB320P with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TSDB320P with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TSDB320P |
|---|---|
| Manufacturer | Hamlin / Littelfuse |
| Description | RELAY TIME DELAY 10SEC CHASSIS |
| Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $24.54 | $23.25 | $21.958 | $20.666 | $19.375 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | TSDB320P | Manufacturer | Hamlin / Littelfuse |
|---|---|---|---|
| Description | RELAY TIME DELAY 10SEC CHASSIS | Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant |
| Quantity Available | 1758 pcs | Data sheet | TSDB Series Datasheet |
| Category | Industrial Controls | Voltage - Supply | 24VDC |
| Timing Initiate Method | Input Voltage, Trigger Signal | Timing Adjustment Method | External Resistor |
| Termination Style | Quick Connect - 0.250" (6.3mm) | Series | TSDB |
| Relay Type | Solid State Relay | Other Names | F10709 |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | Not Applicable |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant |
| Function | Off-Delay | Detailed Description | Off-Delay Time Delay Relay SPST-NO (1 Form A) 0.1 Sec ~ 10 Sec Delay Chassis Mount |
| Delay Time | 0.1 Sec ~ 10 Sec | Contact Rating @ Voltage | - |
| Circuit | SPST-NO (1 Form A) |
