SMD300F/15-2
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SMD300F/15-2 with confidence from Components-World.HK, 1 Year Warranty
Dowload SMD300F/15-2 Details in PDFSee Product Specifications for product details.
Buy SMD300F/15-2 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SMD300F/15-2 |
|---|---|
| Manufacturer | Hamlin / Littelfuse |
| Description | PTC RESET FUSE 15V 3A 2SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 2000 pcs | 4000 pcs | 6000 pcs | 10000 pcs | |
|---|---|---|---|---|---|
| $0.093 | $0.092 | $0.09 | $0.087 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | SMD300F/15-2 | Manufacturer | Hamlin / Littelfuse |
|---|---|---|---|
| Description | PTC RESET FUSE 15V 3A 2SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 230459 pcs | Data sheet | PolySwitch, SMD CatalogSMD300F/15 Spec |
| Category | Circuit Protection | Voltage - Max | 15V |
| Type | Polymeric | Time to Trip | 35s |
| Thickness (Max) | 0.118" (3.00mm) | Size / Dimension | 0.290" L x 0.202" W (7.36mm x 5.12mm) |
| Series | PolySwitch®, SMD | Resistance - Post Trip (R1) (Max) | 50 mOhms |
| Resistance - Initial (Ri) (Min) | 15 mOhms | Ratings | - |
| Packaging | Tape & Reel (TR) | Package / Case | 2-SMD |
| Other Names | RF1835-000 SMD300F/15-2-ND SMD300F/15-2TR SMD300F/152 SMD300F152 |
Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 2A (4 Weeks) |
| Manufacturer Standard Lead Time | 11 Weeks | Lead Spacing | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | - |
| Detailed Description | Polymeric PTC Resettable Fuse 15V 3A Ih Surface Mount 2-SMD | Current - Trip (It) | 6A |
| Current - Max | 40A | Current - Hold (Ih) (Max) | 3A |
| Approvals | CSA, TUV, UL |
