MG12150D-BA1MM
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MG12150D-BA1MM with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MG12150D-BA1MM with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MG12150D-BA1MM |
|---|---|
| Manufacturer | Hamlin / Littelfuse |
| Description | IGBT 1200V 210A 1100W PKG D |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 60 pcs | ||||
|---|---|---|---|---|---|
| $39.45 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | MG12150D-BA1MM | Manufacturer | Hamlin / Littelfuse |
|---|---|---|---|
| Description | IGBT 1200V 210A 1100W PKG D | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 795 pcs | Data sheet | MG12150D-BA1MM |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 1200V |
| Vce(on) (Max) @ Vge, Ic | 1.8V @ 15V, 150A (Typ) | Supplier Device Package | D3 |
| Series | - | Power - Max | 1100W |
| Package / Case | Module | Other Names | F6480 |
| Operating Temperature | -40°C ~ 150°C (TJ) | NTC Thermistor | No |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Cies) @ Vce | 11nF @ 25V | Input | Standard |
| IGBT Type | - | Detailed Description | IGBT Module Half Bridge 1200V 210A 1100W Chassis Mount D3 |
| Current - Collector Cutoff (Max) | 1mA | Current - Collector (Ic) (Max) | 210A |
| Configuration | Half Bridge |
