Home > Products > Circuit Protection > Fuseholders > 03540101ZXGY

03540101ZXGY

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 03540101ZXGY with confidence from Components-World.HK, 1 Year Warranty

Dowload 03540101ZXGY Details in PDF

Request a Quote

Part Number	03540101ZXGY
Manufacturer	Hamlin / Littelfuse
Description	FUSE BLOCK CART 600V 15A PCB
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs	5000 pcs
~~In Stock~~ 116119 pcs
Reference Price (In US Dollars)	1 pcs	5 pcs	10 pcs	50 pcs	100 pcs
	$0.459	$0.444	$0.415	$0.344	$0.286
	$0.279	$0.236	$0.208	$0.186

Product parameter
Data sheet

Product parameter

Part Number	03540101ZXGY	Manufacturer	Hamlin / Littelfuse
Description	FUSE BLOCK CART 600V 15A PCB	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	116119 pcs	Data sheet	354 Series OMNI-BLOK®
Category	Circuit Protection	Voltage	600V
Termination Style	PC Pin	Series	OMNI-BLOK® 354
Other Names	03540101ZXGY-ND 3540101ZXGY 354101-GY 354101GY F1498	Orientation	Horizontal
Number of Circuits	1	Mounting Type	PCB
Moisture Sensitivity Level (MSL)	Not Applicable	Manufacturer Standard Lead Time	13 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Fuseholder Type	Block
Fuse Type	Cartridge	Fuse Size	1/4" Dia x 1 1/4" L (6.4mm x 31.8mm)
For Use With/Related Products	3AB, 3AG	Detailed Description	Fuse Block 15A 600V 1 Circuit Cartridge PCB
Current Rating	15A	Contact Material	Phosphorus Bronze
Contact Finish	Tin
