Home > Products > Connectors, Interconnects > Heavy Duty Connectors - Housings, Hoods, Bases > 19628161271

19628161271

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 19628161271 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	19628161271
Manufacturer	HARTING
Description	CONN BASE SIDE ENTRY SZ16B M25
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1829 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
Reference Price (In US Dollars)	$25.34	$23.847	$23.102	$21.612	$20.419

Product parameter
Data sheet

Product parameter

Part Number	19628161271	Manufacturer	HARTING
Description	CONN BASE SIDE ENTRY SZ16B M25	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1829 pcs	Data sheet	19628161271 Drawing Hoods/Housings Catalog
Category	Connectors, Interconnects	Thread Size	M25
Style	Side Entry	Size / Dimension	4.606" L x 2.244" W x 3.232" H (117.00mm x 57.00mm x 82.10mm)
Size	16B	Series	Han® EMC
Packaging	Bulk	Other Names	1195-7174 19628161271-ND
Operating Temperature	-40°C ~ 125°C	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	7 Weeks	Lock Location	Locking Clip (2) on Base Bottom
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	IP65 - Dust Tight, Water Resistant
Housing Material	Aluminum, Die Cast	Housing Finish	-
Housing Color	-	Features	Feed Through
Connector Type	Base - Box Mount
