Home > Products > Connectors, Interconnects > Heavy Duty Connectors - Housings, Hoods, Bases > 19628101421

19628101421

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 19628101421 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	19628101421
Manufacturer	HARTING
Description	CONN HOOD TOP ENTRY SZ10B M25
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4021 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$8.40

Product parameter
Data sheet

Product parameter

Part Number	19628101421	Manufacturer	HARTING
Description	CONN HOOD TOP ENTRY SZ10B M25	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4021 pcs	Data sheet	19628101421 Drawing Han® High Temp hoods/housings
Category	Connectors, Interconnects	Thread Size	M25
Style	Top Entry	Size / Dimension	2.858" L x 1.693" W x 1.772" H (72.60mm x 43.00mm x 45.00mm)
Size	10B	Series	Han® EMC
Packaging	Bulk	Other Names	1195-3865 19628101421-ND
Operating Temperature	-40°C ~ 125°C	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	7 Weeks	Lock Location	Locking Clip (2) on Base Bottom
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	IP65 - Dust Tight, Water Resistant
Housing Material	Aluminum, Die Cast	Housing Finish	-
Housing Color	-	Features	-
Connector Type	Hood
