17030772201
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 17030772201 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 17030772201 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 17030772201 |
|---|---|
| Manufacturer | HARTING |
| Description | HAR-BUS HM MEL., TYP C, AFS 2, T |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 20 pcs | 40 pcs | 60 pcs | |
|---|---|---|---|---|---|
| $2.135 | $2.05 | $1.879 | $1.794 | ||
| 100 pcs | 260 pcs | 500 pcs | 1000 pcs | ||
| $1.708 | $1.495 | $1.452 | $1.239 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 17030772201 | Manufacturer | HARTING |
|---|---|---|---|
| Description | HAR-BUS HM MEL., TYP C, AFS 2, T | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 29488 pcs | Data sheet | 1703077x201 DrawingDevice Connectivity Catalog |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Press-Fit | Series | har-bus® HM |
| Pitch | 0.079" (2.00mm) | Packaging | Tube |
| Other Names | 1195-5258 17030772201-ND |
Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 5 + 2 | Number of Positions Loaded | All |
| Number of Positions | 77 (55 + 22 Ground) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 6 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Board Guide, Shielded |
| Detailed Description | 77 (55 + 22 Ground) Position Header, Male Pins Connector 0.079" (2.00mm) Through Hole | Current Rating | 1A |
| Contact Finish Thickness | - | Contact Finish | Gold or Gold-Palladium |
| Connector Usage | Backplane-to-Daughtercard | Connector Type | Header, Male Pins |
| Connector Style | C 11 |
