15220122401000
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 15220122401000 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 15220122401000 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 15220122401000 |
|---|---|
| Manufacturer | HARTING |
| Description | HAR-FLEX THR STR FEMALE 9.05MM 1 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 220 pcs | 440 pcs | 660 pcs | 1100 pcs | 1540 pcs |
|---|---|---|---|---|---|
| $1.437 | $1.257 | $1.221 | $1.041 | $1.006 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 15220122401000 | Manufacturer | HARTING |
|---|---|---|---|
| Description | HAR-FLEX THR STR FEMALE 9.05MM 1 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 37851 pcs | Data sheet | 1522yyyy401yyy Drawinghar-flex® THR Series Catalog |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Solder | Style | Board to Board |
| Series | har-flex® | Row Spacing - Mating | 0.050" (1.27mm) |
| Pitch - Mating | 0.050" (1.27mm) | Packaging | Tape & Reel (TR) |
| Other Names | 1195-5663-2 | Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 12 | Mounting Type | Surface Mount |
| Material Flammability Rating | UL94 V-0 | Mated Stacking Heights | - |
| Manufacturer Standard Lead Time | 15 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Liquid Crystal Polymer (LCP) | Insulation Color | Black |
| Ingress Protection | - | Features | Board Guide, Pick and Place, Solder Retention |
| Fastening Type | Push-Pull | Detailed Description | 12 Position Receptacle Connector 0.050" (1.27mm) Surface Mount Gold |
| Current Rating | - | Contact Type | Female Socket |
| Contact Shape | Square | Contact Material | Copper Alloy |
| Contact Length - Post | - | Contact Finish Thickness - Post | - |
| Contact Finish Thickness - Mating | - | Contact Finish - Post | Tin |
| Contact Finish - Mating | Gold | Connector Type | Receptacle |
| Applications | - |
