Home > Products > Connectors, Interconnects > D-Sub, D-Shaped Connectors - Contacts > 09692812550

09692812550

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09692812550 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	09692812550
Manufacturer	HARTING
Description	DSUB MA STR HIGH VOLTAGE CONTACT
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 25707 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$2.405	$2.304	$2.104	$2.004
	$1.903	$1.703	$1.603	$1.403

Product parameter
Data sheet

Product parameter

Part Number	09692812550	Manufacturer	HARTING
Description	DSUB MA STR HIGH VOLTAGE CONTACT	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	25707 pcs	Data sheet	09692812550 Drawing
Category	Connectors, Interconnects	Wire Gauge	20 AWG
Type	Power	Termination Finish Thickness	51.2µin (1.30µm)
Termination Finish	Gold	Series	-
Packaging	Bulk	Other Names	1195-2844 9692812550
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	8 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Features	Insulator, PTFE
Detailed Description	D-Sub Contact Male Pin Gold 20 AWG Solder Machined	Contact Type	Male Pin
Contact Termination	Solder	Contact Size	-
Contact Material	-	Contact Form	Machined
Contact Finish Thickness	51.2µin (1.30µm)	Contact Finish	Gold
