09681635811
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09681635811 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 09681635811 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 09681635811 |
|---|---|
| Manufacturer | HARTING |
| Description | CONN D-SUB PLUG 9POS R/A SOLDER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.324 | $1.271 | $1.165 | $1.112 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.059 | $0.927 | $0.90 | $0.768 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 09681635811 | Manufacturer | HARTING |
|---|---|---|---|
| Description | CONN D-SUB PLUG 9POS R/A SOLDER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 39393 pcs | Data sheet | 0968163x811,812 Drawing |
| Category | Connectors, Interconnects | Wire Gauge | - |
| Voltage Rating | - | Termination | Solder |
| Shell Size, Connector Layout | 1 (DE, E) | Shell Material, Finish | Steel |
| Series | - | Packaging | Bulk |
| Other Names | 1195-2801 9681635811 |
Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 2 | Number of Positions | 9 |
| Mounting Type | Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 9 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Housing Material | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Flange Feature | Housing/Shell (M3) |
| Features | Board Lock, Grounding Indents | Detailed Description | 9 Position D-Sub Plug, Male Pins Connector |
| Current Rating | 6.5A | Contact Type | Signal |
| Contact Material | Copper Alloy | Contact Form | Stamped |
| Contact Finish Thickness | 30.0µin (0.76µm) | Contact Finish | Gold or Gold-Palladium |
| Connector Type | Plug, Male Pins | Connector Style | D-Sub |
| Color | - | Backset Spacing | 0.318" (8.08mm) |
